【 Performance and use 】
Dremfu inner circle cutting fluid DK-600 is made of surfactants, lubricants, anti-rust agents and other additives under strict production process control. It is suitable for the inner circle cutting of glass, sapphire glass and crystal of various materials. This product is easy to use, when in use, the active ingredient should be kept above 5%, that is, diluted by 1:20 (coolant: water, wt/wt), and can be used after mixing evenly. Due to different processing conditions, if there is loss or loss during use, the stock liquid and water should be added proportionally.
【 Main technical parameters 】
item | Technical indicators | Test method |
External view | Yellowish brown transparent liquid | GB6144-85 |
pH value | 10.15 ± 0.50 | GB6144-85 |
Defoaming (ml) | 2 or less | GB6144-85 |
Specific weight (g/ml) | 1.07 ± 0.05 | Pycnometer method |
Surface tension (dyn/cm) | 30 or less | GB6144-85 |
Storage stability | conjunctive | GB6144-85 |
corrosiveness | Grade A cast iron | GB6144-85 |
Rust resistance | Grade A cast iron | GB6144-85 |
【 Instruction 】
1. Dilution of the stock solution with 20-30 times tap water or deionized water is the working liquid, or depending on the difficulty of processing and the actual situation.
2. During use, the working liquid can be supplemented at a concentration of 3-5%.
【 Packaging 】
18L/ barrel, 25L/ barrel, 200L/ barrel.
Inner circle cutting fluid DK-600.pdf
Features
Excellent lubrication performance: Inner Circle Cutting Fluid has excellent lubricity, which can significantly reduce the friction between the tool and the workpiece during the cutting process, reduce wear, and extend the service life of the tool.
Strong cooling capacity: Inner Circle Cutting Fluid has excellent cooling performance, which can effectively take away the heat generated during the processing process, prevent the workpiece and cutting tools from being deformed or damaged due to overheating, and ensure the processing accuracy and surface quality.
Rust and corrosion resistance: The anti-corrosion components added to the Cutting Fluid can effectively prevent the processing equipment and the surface of the workpiece from rusting, keep the processing environment clean, and increase the service life of the mold and tools.
Good cleanliness: Inner Circle Cutting Fluid can clean the metal chips and tiny particles generated during the processing process to prevent them from affecting the processing accuracy, ensure the smooth surface of the workpiece, and reduce secondary pollution.
Environmentally friendly and low toxicity:
DK-600 cutting fluid adopts an environmentally friendly formula with low toxicity, will not have a negative impact on the health of workers or the environment, and meets the needs of modern manufacturing industry for environmental protection and safety.
Economical and practical:
When using, just mix the active ingredients with water in a certain proportion to easily obtain the ideal cutting effect. It is easy to operate and economical and efficient.
Advantages
Improve processing efficiency:
Due to its strong lubrication and cooling effects, it can reduce cutting resistance and temperature rise during processing, thereby increasing cutting speed and feed speed, and improving overall processing efficiency.
Extend tool and mold life:
The lubricating effect of the cutting fluid can effectively reduce tool wear and prevent frequent tool replacement caused by excessive wear, thereby reducing maintenance costs and extending the service life of tools and molds.
Improve workpiece surface quality:
By reducing friction and heat accumulation, it can reduce the surface roughness of the workpiece, improve the surface finish, and ensure that the accuracy and appearance of the workpiece meet the requirements.
Strong adaptability:
DK-600 cutting fluid is suitable for the processing of a variety of hard materials, especially in the inner circle cutting of hard and brittle materials such as glass, sapphire glass, and crystal, and can meet different production needs.
Low foam and low volatility:
It has low foam generation and volatility, and can maintain stable performance even in high-temperature and high-load processing environments, ensuring the smooth progress of the processing process.
Application areas
Glass processing: It is very suitable for inner circle cutting of glass materials, especially in the precision processing of glass products, which can effectively reduce heat accumulation and ensure processing accuracy and surface quality.
Sapphire glass processing: Sapphire glass has high hardness and is difficult to cut. With its excellent lubrication and cooling performance, DK-600 can effectively extend tool life and improve processing efficiency in the inner circle cutting of sapphire glass.
Crystal processing: Crystal materials are relatively fragile and easily broken due to high temperatures. Using DK-600 can maintain a low cutting temperature, avoid cracks and breakage on the crystal surface, and ensure accuracy and quality.
Precision mold processing: In the inner circle cutting of precision molds, the excellent lubricity of DK-600 can help reduce tool wear, improve mold processing accuracy, and extend mold service life.
Electronic component processing: The electronics industry has high requirements for precision and surface quality. DK-600 can effectively meet this demand and ensure surface quality and processing efficiency during the internal cutting process of electronic components.
Optical device processing: During the processing of optical devices such as lenses and fiber optic connectors, DK-600 can keep the processing area clean, reduce surface scratches and unevenness, and ensure the quality of optical products.
Carbide processing: In the precision cutting of carbide and other difficult-to-process materials, DK-600 effectively reduces heat accumulation during cutting and improves processing accuracy and part quality through its powerful cooling and lubrication properties.
As a cutting fluid designed specifically for hard materials, Glass Cutting Fluid has become an indispensable tool in the field of precision machining due to its excellent lubricity, cooling, corrosion resistance and environmental protection. It can significantly improve processing efficiency, extend tool life, improve workpiece surface quality, and reduce production costs. It is widely used in glass, sapphire glass, crystal, precision molds and other fields.
